| Stock: 50 GLB-3 | Manufacturer: Eager Beaver Trailer |
Detailed Specs
Additional Information
OIL FIELD LOWBOYS
122,000 lbs.
21,600 lbs
Width: 8 ft. 6 in. Height: 43in. (Loaded)
Mainrails: fabricated 24” Deep I-Beam. Siderails: fabricated 16” Deep I-Beam
10” x 12 lbs. per ft. I-Beam, pierced through mainbeam (18” spacing)
2” Nominal Apitong wood ahead of wheels, 3/8” smooth steel over wheels
Sealed LED Lights
USA Star PLUS Sealed Modular Wiring Harness
8- Roto Rings Per Side; Fixed D-Rings on Rear of Neck and Tailboard
Black,Yellow, Blue (standard) Imron Paint
Twelve 255/70R22.5 (H) Steel Belted Radial (Yokohama)
Disc Type Hubs
8.25 x 22.5 Disc Type Wheels, Stemco Oil Seals, Hub Piloted
Air Ride (Combined Capacity 75,000 lbs) with Dump Valve; Lift 1st Axle
Three 5” Diameter 25,000 lbs. each, H.M. series bearings
Description
50 Ton Fixed Gooseneck Oilfield – ABS Air Brake Axles
